Burgmann MBS100 METAL BELLOW SEAL replacement


  • Burgmann MBS100 METAL BELLOW SEAL replacement

Name:Burgmann MBS100 METAL BELLOW SEAL replacement

Product Description

Features
Equivalent MBS100
For unstepped shafts
Rotating bellows
Single Seal
Balanced
Independent of direction of rotation
Operating range
Shaft diameter: d1 = 20 … 100 mm (0.75" … 4")
Pressure: p1 = … 25 (16*) bar 363 (232*) PSI
Temperature: t = -40 °C … +220 (160*) °C (-40 °F … 428 (320*)) °F
Sliding velocity: vg = 20 m/s (66 ft/s)
* Operating limits for material combination Q1/Q1
Materials
Seal face: Silicon carbide (Q12), Carbon graphite (A)
Seat: Silicon carbide (Q1)
Bellows: Inconel® 625 (T3)
Secondary seals: FKM (V)
Metal parts: Duplex (G1)
Recommended applications
Process industry
Refining technology
Power plant technology
Chemical industry
Hot media
Cold media
Highly viscous media
Pumps
Special rotating equipment
