Product details

Flange mounted on the end cover, ensure that under the condition of the vibration bearing isolator installed stability.Between dynamic and static ring bolt positioning and prevent under extreme conditions, the separation of dynamic and static ring.

Speed requirements: no higher than 60 m/s
Temperature : - 35 oc to 210 oc
Using axial size: 20 mm to 4000 mm

Shaft beating: 0 ~ 0.4 mm

Main applications:

 Pump. Motor, gear box. Rotary valve. Blender. Mixer. Conveying equipment. Process pump, screw pump, boiler injection pumps. All kinds of parallel axis, cooling tower fan. Turbine. Bearing seat. The centrifuge. Coal mill. Crusher. Screw conveyor. Refining machine. The roll.

Axis displacement: 0 ~ 0.5 mm
