BURGMANN METAL BELLOW MFLWT80 FOR HIGH TEMPERATURE USE IN OIL PUMPS AND CHEMICAL PUMPS
| Name: | BURGMANN METAL BELLOW MFLWT80 FOR HIGH TEMPERATURE USE IN OIL PUMPS AND CHEMICAL PUMPS |
Product Description
Operating Limits:
Pressure: ≤2MPa
Speed: ≤20m/s
Temperature: -73℃~+427℃
otary Ring (SiC/Carbon/TC)
Stationary Ring(SiC/TC)
Secondary Seal (Flexible Carbon)
Metal Bellows (SUS316L/AM350/Inconel718/Titanium/Hastelloy-C/AIIoy-20)
Other Parts (SUS304/SUS316/Titanium/Hastelloy-C
Features:
⑴For unstepped shafts
⑵Single Seal
⑶Balanced
⑷Independent of direction of rotation
⑸Metal bellows rotating
Advantages:
⑴For extreme high temperature ranges
⑵No dynamically loaded O-Ring
⑶Self cleaning effect
⑷Short installation length possible
⑸Pumping screw for highly viscous media available (dependent on direction of rotation)
Suggested Applications:
⑴Process industry
⑵Oil and gas industry
⑶Refining technology
⑷Petrochemical industry
⑸Chemical industry
⑹Pulp and paper industry
⑺Hot media
⑻Highly viscous media
⑼Pumps
⑽Special rotating equipment
