Jiangyin Rochman Seals Co., Ltd. specializes in designing, manufacturing, and selling EKATO in Germany

HWL/ESD mechanical seals are widely used in coal-fired power plant absorption tower side stirrers.

Germany EKATO stirrer HWL/ESD mechanical seal, sealing surface are made of high-quality non-pressure sintering silicon carbide, matrix material can be selected SUS316L, 2205, 2507 and so on. The structure has the advantages of anti-clogging, anti-abrasion, anti-corrosion and the like, and the service life is more than double that of ordinary mechanical seals.

Structural features:

Single-end cartridge type bearing housing with mechanical seal. Easy to install and easy to use. Balance, arbitrary rotation.

The internal working length is short. Static ring compensation multiple springs are not in contact with the media.

Applicable media:

Contains gypsum, lime slurry and other impurities with high levels of media.

Working parameters:

Fixture content: ≤30%

Temperature: ≤120°C

Pressure: ≤1.6MPa

Shaft diameter: ≤ 120mm

main application:

The seal is mainly used in the side stirrer of the absorption tower in the coal-fired power generation flue gas desulfurization device, and it can also be used in the reaction kettles of chemical and papermaking industries. The seal can completely replace the mechanical seal on the EKATO stirrer imported from Germany.

Common seal models:

HWL2060N HWL2060L HWL2080N HWL2080L

HWL2100N HWL2100L HWL2120N HWL2120L

ESD-60 ESD42L060R31V ESD-80 ESD42L080R31V

ESD-100 ESD42L100R31V ESD-120 ESD42L120R31V
